MXT
Features
● Low insertion loss
● High return loss
● High interface performance
● High corrosion resistance
● UL standard accessories, comply with RoHS.
● Screw type connection,easy to link properly.
Area of applications
● Telecom network
● Optical laser
● Optical test equipment
● Optical communication equipment
● CATV network
Specifications
Item | Single mode | Multi mode | |
Insertion loss | PC<0.3dB APC<0.2dB | <0.3dB | |
Return loss | PC>45dB APC>60dB | >25dB | |
Insert-pull test | 1000(times) <0.3dB | ||
Operating temperature | -40℃ ~ +75℃ | ||
Ceramic ferrule spec | 125.5um concentricity deviations:<1um | 127um concentricity deviations:<3um | |
Suitable fiber | PC/APC(9/125um) | PC(50/125um,62.5/125um) |
Ordering Information
● Supply SM,MM, single connectors
● Supply all set connectors and accessories(SKD)
● Supply 3.0mm, 2.0mm, 0.9mm boot.
