MXT3308
MXT
Description
MXT3308 handheld return loss tester is used to measure the return loss in the field fiber optic linking, in order to adjust the quality of the optic fiber end-face, and to make sure the fiber optic communication is in good condition. This MXT3308 handheld return loss tester can realize measurement of Return Loss, Insertion Loss, Output power, and also can be used as the laser source. Moreover, it has the data storage function of 500 measurement items.
Technical Specification
Return Loss Testing | |
Wavelength（nm） | 1310/1550 |
Plus Width（nm） | <5 |
Displaying range（dB） | 6~70 |
Accuracy（dB） | ±0.5 |
Resolution（dB） | 0.01 |
Power Meter | |
Wavelength Rang（nm） | 850 ～ 1650 |
Calibration wavelength（nm） | 850、 1300、 1310 、 1490、 1550 、 1625 |
Detector type | InGaAs |
Displaying Unit | dBm 、dB 、W |
Displaying Range（dBm） | －70 ～＋6 |
Max. Output Power（dBm） | ＋6 |
Resolution（dB） | 0.01 |
Accuracy（dB） | 0.3 |
Laser Source | |
Wavelength（nm） | 1310/1550 |
Plus Width（nm） | <5 |
Max Output Power（dBm） | -3 |
Stability（dB，30min） | ± 0.05 |
Modulation（HZ） | CW, 270, 1K, 2K |
