Applications
● WDM system
● CATV network
● Telecom network
● Erbium-Doped in fiber optical amplifier
● Fiber optical sensor
Features
● Low insertion loss
● Low polarization related loss
● High wavelength isolation
● Stable function in different environment
● Compact structure
Performance
Wavelength(nm) | 1310/1550 |
BroadBand(nm) | ±15 |
Insertion loss(dB) | ≤0.30 |
Isolation(dB) | ≥18 |
PDL(dB) | ≤0.10 |
Directivity(dB) | ≥55 |
Operation Temperature Range(℃) | -40℃ ~ +85℃ |
Ordering Information
Wavelength(nm) | End | Package Dimension(mm) | Fiber type and length | Connectors type | |
1310/1550 | 1X2 | 3x54mm | 9/125um(fiber diameter) Length:1m | ST/PC |
Encapsulation
Item | 1x2 or 2x2 | ||
Pigtail type | 250um bare fiber | 900um loosen tube | 3mm loosen tube |
Size | ф3xL55 | ф3xL55 | L90xW15xH7 |
Pigtail length | 1 meter or customized |
Competitive Advantage
MXT strictly enforce the ISO9001 quality management system, companies with good facilities and qualified human resources management to ensure product quality stability and excellent performance; and good after-sales service, to win the trust of customers, products exported to Europe and the United States and Southeast Asian countries.
