MXT
Applications
● CWDM System CWDMXT
● PON Networks PON
● CATV Links
Features
● Low Insertion Loss
● High Isolation
● Low PDL
● Compact Design
● Good channel-to-channel uniformity
● Wide Operating Wavelength: From 1260nm to 1620nm
● Wide Operating Temperature: From -40℃ to 85℃
● High Reliability and Stability
Specifications
Parameters | 1x2 | 1x4 | 1x8 | 1x16 | |
Center Wavelength (nm) | ITU, ITU+1 | ||||
Passband (nm) | ITU±6.5 | ||||
Operating Wavelength (nm) | 1460~1620 or 1260~1620 | ||||
Channel Space (nm) | 20 | ||||
Fiber Type | SMF-28e or customer specified | ||||
IL (dB) (P/A Grade) | 0.7/1.0 | 1.4/1.7 | 2.0/2.5 | 3.5/4.0 | |
Isolation (dB) | Adjacent Channel | 30 | |||
Non-Adjacent Channel | 50 | ||||
Ripple (dB) | 0.3 | 0.4 | 0.5 | 0.5 | |
PDL (dB) | 0.2 | ||||
PMD (ps) | 0.1 | ||||
RL (dB) | 45 | ||||
Directivity (dB) | 50 | ||||
Maximum Optical Power (mw) | 500 | ||||
Operating Temperature (℃) | -40～85 | ||||
Storage Temperature (℃) | -40～85 | ||||
BOX Package (mm) | 100*80*10 | 140*115*18 | |||
LGX Package | 1U, 2U | ||||
19’’ Rack mount Package | 1U | ||||
Compliance
● Telcordia GR-1209-CORE-2001
● Telcordia GR-1221-CORE-1999
● RoHS
MXT strictly enforce the ISO9001 quality management system, companies with good facilities and qualified human resources management to ensure product quality stability and excellent performance; and good after-sales service, to win the trust of customers, products exported to Europe and the United States and Southeast Asian countries.
