Application
● Metropolitan area network
● CATV system
● Connecting network
● CWDM system
● Broadband wavelength division system
Features
● Maximum 3pcs LGX Module
● Plastic pin fixture, easy for load and unload
● Customized channel no.
● Mux/Demux can be installed at the same LGX box
● OADM can be installed by two-direction
Performance
Parameters | Add | Drop | |
Operating Wavelength (nm) | 1471, 1491 or 1470, 1490 etc. | ||
Center Wavelength Accuracy (nm) | ± 0.5 | ||
Channel Space (nm) | 20 | ||
Channel Passband (@-0.5dB bandwidth)(nm) | >13 | ||
IL (dB) | Add/Drop Ch. | < 0.6 | |
Express Ch. | < 0.6 | ||
Add/Drop Channel Ripple (dB) | < 0.3 | ||
Add/Drop Isolation (dB) | Adjacent Channel | N/A | >30 |
Non-Adjacent Channel | N/A | >40 | |
Express Channel Isolation (dB ) | >25 | ||
IL Temperature Sensitivity (dB/℃) | <0.003 | ||
Wavelength Temperature Shifting (nm/℃) | <0.002 | ||
Polarization Dependent Loss (dB) | <0.10 | ||
Polarization Mode Dispersion (ps) | <0.1 | ||
Directivity (dB) | >50 | ||
RL (dB) | >45 | ||
Maximum Optical Power (mw) | 300 | ||
Operating Temperature (℃) | 0 ~ +70 | ||
Storage Temperature (℃) | -40 ~ +85 | ||
Rack (mm) | L430 x W250 x H43 | ||
Competitive Advantage
MXT strictly enforce the ISO9001 quality management system, companies with good facilities and qualified human resources management to ensure product quality stability and excellent performance; and good after-sales service, to win the trust of customers, products exported to Europe and the United States and Southeast Asian countries.
