CPU and Memory | CPU | GX6605S |
| MIPS 34K@600MHz |
DDR2 | DDR2 512Mbit(64MByte) |
Flash | 32Mbit(4MByte) |
Tuner | Connector Type | F-Female *1 for LNB Input，F-Female* 1 for LOOP OUT |
Input Frequency | 950MHz~2150MHz |
Signal Input Level | -65~-25dBm |
Input Impedance | 75 Ohm |
LNB Power Out | 13V/18V, Imax=500mA, overload protection |
LNB Waveform Out | 0/22kHz switch |
Demodulation scheme | QPSK/8PSK: 1~55Msps |
Code Rate | 1/2, 3/5, 2/3, 3/4, 4/5, 5/6, 8/9,9/10 (QPSK) 3/5, 2/3, 3/4, 5/6, 8/9, 9/10(8PSK) |
DiSEqC | 1.0, 1.1, 1.2, USALS, Unicable |
FFT | 1k,2k,4k,8k normal and extended,16knormal and extended,32k normal and extended. |
FECE mode | 64800 bits, 16200 bits |
Guard Interval | 1/4, 19/256, 1/8, 19/128, 1/16, 1/32, 1/128 |
Software Function | EPG | Fully support to 7 days Electronic Program Guide(EPG) |
Video Decoding | MPEG4, MPEG2,MPEG1, H.264 |
Video Format | avi, mp4, mkv, mov, dat, flv, mpg, vob, 3gp, ts |
Audio Decoding | MPEG-1/2/3, wma |
Audio Format | mp3, wma, ogg |
Picture Format | JPEG, BMP |
Video Resolution | 480i, 480P, 576i, 576P, 720P, 1080i, 1080P |
Video Aspect Ratio | 4:3(LB/PS), 16:9(LB/FIT) |
Analog Video System | PAL, NTSC |
OSD Language | 12 kinds of language(English,French,German,Spanish,Portuguese, Russia,Turkish,Polish,Arabic,Persian,Thai,Vietnamese) |
LCN Sort | Support Logic Channel Number(LCN) |
Teletext | VBI insertion for Teletext |
Time Shift | Support Time Shift |
Hardwar Interface | Video Output | RCA(CVBS, L/R), HDMI Interface |
SPDIF Output | 1*Coaxial |
USB Interface | 2*USB2.0 |
RS-232 | 1*RS-232 |
Button | OK, MENU, CH-, CH+, VOL-, VOL+ |
Power supply | AC Input 100~240V 50Hz, 15WMax |
RF OUT | Optional |
