RG59+2 POWER WIRES

Availability:
Inquire

RG59+2 POWER WIRES

  • RG59+2

  • MXT

BASIC CONSTRUCTION





RG59+2POWER WIRES

Nominal Impedance(Ω)

75

Nominal Velocity of Propagation(%)

85

Nominal Capacitance (pF/m)

50

Sparker Test (VAC)

4000

SRL(dB)

20

Attenuation
[@68°F(20℃)]

Frequency(MHz)

Maximum(dB/100ft)

Maximum(dB/100m)

5

0.86

2.82

55

2.05

6.73

300

4.45

14.60

600

6.20

20.34

1000

8.12

26.64

1450

9.88

32.41

1800

11.81

38.72

2200

13.05

42.78
