Applications
● Fiber to the home(FTTH)
● Fiber to the building（FTTB）
● Local area netwoks
● Wide area networks
Features
● Small size and light weight for easy installation compact body
● Wall mounted with mechanical protection function
● Available for FC,SC,ST,LC adatpers
● Fiber can get in from bottom or side
● Anti-UV, Ultra violet resistant and rainfall resistant
Specifications
Item | FTTH-6 | FTTH-8 | FTTH-12 | FTTH-16 | FTTH-24 | FTTH-48 |
Size(HxWxD)mm | 180x168x30 | 300x100x45 | 150x110x30 | 200x215x24 | 260 x320 x90 | 86x86x10 |
Cable diameter(mm) | Ф5～Ф10 |
Cable ports | 2 | 4 | 2 |
Adapter ports | 8 | 1 | 4 | 8 | 16 | 2 |
Max capacity of splice | 16 | 12 | 4 | 16 | 2 |
Suitable Adapter | SC,LC,E2000 | SC,FC,LC,E2000 |
Materials | ABS,PC or ABS+PC |
Environmental Temperature(℃) | －25～40 |
Competitive Advantage
MXT strictly enforce the ISO9001 quality management system, companies with good facilities and qualified human resources management to ensure product quality stability and excellent performance; and good after-sales service, to win the trust of customers, productsexported to Europe and the United States and Southeast Asian countries.
