Specifications
● High Return Loss & Low Insertion Loss
● High reliability and stability
● Green Production, CE, RoHS Standard
Parameter
Mode | Single mode | Multimode | |
Polish | UPC | APC | PC |
Insertion Loss | ≤0.2dB | ≤0.3dB | ≤0.2dB |
Return Loss | ≥55dB | ≥65dB | ≥35dB |
Interchangeability | ≤0.2dB | ||
Salt Spray | ≤0.1dB | ||
Repeatability | ≤0.1dB (1000 times) | ||
Vibration | ≤0.2dB (550Hz 1.5mm) | ||
Temperature | ≤0.2dB (-40+85 sustain 100 hours) | ||
Humidity | ≤0.2dB (+25+65 93 R.H.100 hours) | ||
Apex Offset | 0μm ~ 50μm | ||
Radius of Curvature | 7mm ~ 25mm | ||
Standards-Compliant | ROHS,IEC and GR-326 | ||
Fiber cable performance specifications | |||
Fiber type | Min.Bandwidth | Distance | attenuation |
62.5/125 | 850/1300nm 200/500 MHz/Km | @100Mbps 2km @1Gig 220m | 850/1300nm 3.0/1.0dB/km |
50/125 | 850/1300nm 500/500 MHz/Km | @100Mbps 2km @1Gig 500m | 850/1300nm 3.0/1.0dB/km |
50/125 10Gig Optimized | 850/1300nm 2000/500 MHz/Km | @100Gig Varies by VCSEL typical 300m 2850nm | 850/1300nm 3.0/1.0dB/km |
9/125 | 1310/1550nm Approx 100 Terahertz | Up to 100km Varies by transceiver | 1310/1550nm 0.4/0.3dB/km |
Fiber type | Single mode:1,9/125-G652D |
Multimode:4,50/125-OM2 | |
Fiber | Corning,China Fiber,other |
Connector1 | SC, FC, LC, ST, MU, DIN, MTRJ, E2000, MPO, SMA, D4 and others |
Polishing | PC, UPC, APC, MTRJ Male connector,MTRJ female connector |
Connector2 | SC, FC, LC, ST, MU, DIN, MTRJ, E2000, MPO, SMA, D4 and others |
Polishing | PC, UPC, APC, MTRJ Male connector,MTRJ female connector |
Cord type | Simplex ,Duplex |
Cable diameter | 0.9mm, 2.0mm, 1.8mm, 3.0mm |
Cable jacket | PVC, LSZH, OFNR, OFNP |
length(M) | 0.5m, 1m, 3M, 5m, 10m, 20m, 200m |
Application
● Optical fiber communications system
● Optical fiber access networks
● Optical fiber CATV
● Optical fiber test equipments
● Optical fiber data communication
Competitive Advantage
MXT strictly enforce the ISO9001 quality management system, companies with good facilities and qualified human resources management to ensure product quality stability and excellent performance; and good after-sales service, to win the trust of customers, products exported to Europe and the United States and Southeast Asian countries.
