Applications
● CATV
● Telecom network
● Optical test equipment
● Local area networks
● Wide area networks
● Data processing Networks
Features
● Low insertion loss value
● High back reflection loss value
● Stable capability and high reliability
● Precis connector
● Excellent mechanical capability
● Boots in a variety of colors
Specifications
Item | Single Mode | Multi Mode |
Insertion Loss | ≦0.2dB | ≦0.3bB |
Return Loss | PC≥50dB, UPC≥55dB, APC≥60dB |
Insert-pull Test | 1000 times |
Repeatability | ≦0.1 |
Tensile strength | ≥10KG |
Operating Temperature | -40℃ ~ +85℃ |
Ceramic Ferrule Specification | 125.5um concentricity deviations:≦1um | 127um concentricity deviations:≦3um |
Suitable Fiber | 9/125um | 50/125um,62.5/125um |
Competitive Advantage
MXT strictly enforce the ISO9001 quality management system, companies with good facilities and qualified human resources management to ensure product quality stability and excellent performance; and good after-sales service, to win the trust of customers, products exported to Europe and the United States and Southeast Asian countries.
