Loose Tube Double Sheath Underground Armored Cable(GYTA53)

  • GYTA53
  • MXT

Model Number

GYTA53

Fiber Count

12-72

Out Sheath

PE

Application

Duct/Aerial/Direct Buried

Standard

IEC 60794-1,YD/T901-2010

Storage/Operation Temperature

-40℃~+70℃

OEM

Avaliable

Product Name

Outdoor Direct Burial Cable

Fiber Type

G652D/G657A1

Certification

ISO9001


The fibres,250μm,are positioned in a loose tube made of a high modulus plastic.
The tubes are filled with a waterresistant filling compound.A steel wire,sometimes sheathed with polyethylene(PE) for cable with high fiber count,locates in the center of core as a metallic strength member. Tubes (and fillers) are stranded around the strength member into a compact and circular core. An Aluminum Polyethylene Laminate (APL) is applied around the cable core,which is filled with the filling compound to protect it from water ingress,then, the cable core is completed with a PE sheath .After the PSP is longitudinally applied over the inner sheath,the cable is completed with a PE outer sheath.

Applications
● Duct, Aerial, Direct bruied.
● High speed optical routes in buildings(FTTX)

Characteristics
● Good mechanical and temperature performance
● High strength loose tube that is hydrolysis resistant
● Specially designed compact structure is good at preventing loose tubes from shrinking
● Special tube filling compound ensure a critical protection of fiber
● PE sheath protects cable from ultraviolet radiation
● Steel wire used as the central strength member
● Loose tube filling compound
● APL moisture barrier


Fiber count

Nominal diameter
(mm)

Nominal weight
(kg/km)

Max fiber
per tube

No. Of (tubes+fillers)

Allowable tensile load
(N)

Allowable load resistance
(N/100mm)

Short term

Long term

Short term

Long term

2-36

13.9

202

6

6

3000

1000

3000

1000

38-72

15.1

241

12

6

3000

1000

3000

1000

74-96

17.1

290

12

8

3000

1000

3000

1000

98-120

18.6

333

12

10

3000

1000

3000

1000

122-144

20.2

381

12

12

3000

1000

3000

1000

>144

Design according to your requirement.


Ordering Information

Rolled by wooden drums. 2km-3km per drum or other required.
2. Sheath mark

The following printing is applied at 1-meter intervals.
a. Supplier: MXT or as customer required
b. Standard Code(Product Type, Fiber Type, Fiber Count)
c. Year of manufacture: xxx
d. Length marking in meters
