MXT
Applications
● CATV
● Telecom network
● Optical test equipment
● Local area networks
● Wide area networks
● Data processing Networks
Features
● Low excess loss and high performance
● High back reflection loss value
● Customized packaging and configuration
● GR – 1221 and GR – 1209 compliance
Specifications
Type | 2x2 | 2x4 | 2x8 | 2x16 | 2x32 | 2x64 | |
Fiber type | 9/125um SMF – 28e or customer appoint | ||||||
Operating Wavelength(nm) | 1260 ~ 1650 | ||||||
Insertion loss(dB) | Typical | 4.0 | 7.0 | 10.5 | 13.5 | 16.5 | 20.5 |
（p/s）Max | 4.1/4.3 | 7.4/7.6 | 10.8/11.0 | 14.3/14.5 | 17.3/17.5 | 20.7/21.5 | |
Loss Uniformity(dB) - Max | 0.8 | 0.8 | 1.5 | 2.0 | 2.5 | 2.5 | |
Polarization Dependent Loss(dB) - Max | 0.2 | 0.2 | 0.3 | 0.4 | 0.4 | 0.4 | |
Dimensions(W*H*L)(mm) Ribbon/Bare Fiber | 4*4*50 | 4*4*50 | 4*4*50 | 4*7*60 | 4*7*60 | 4*12*60 | |
Dimensions(W*H*L)(mm) ABS BOX(0.9/2.0/3.0mm) | 100*80*10 | 120*80*18 | 141*141*18 | ||||
Directivity(dB) - Min | 55 | ||||||
Return Loss(dB) - Min | UPC:50 APC:60 | ||||||
Operation Temperature(℃) | -45 ~ +85 | ||||||
Storage Temperature(℃) | -45 ~ +85 | ||||||
Connector type | FC/SC/ST/LC/MU | ||||||
Competitive Advantage
MXT strictly enforce the ISO9001 quality management system, companies with good facilities and qualified human resources management to ensure product quality stability and excellent performance; And good after-sales service, to win the trust of customers, productsexported to Europe and the United States and Southeast Asian countries.
