Specifications
● Fiber To The Home (FTTH)
● Passive Optical Networks (PON / GPON / EPON )
● CATV Network (Cable Television Network) Communication Systems
● Fiber Optic Test Equipment
● Fiber Optic Sensing
● Local Area Networks (LAN)
● Excellent Environmental
Features
● ALL fiber construction
● High Reliability
● Outstanding Optical Performance
● Different Fiber Types Available
Performance
Parameter | Unit | Premium | A | B | ||
Operating Wavelength | nm | 1310±20, 1550±20 /1310±40, 1550±40 or Others | ||||
Excess Loss | Typ. | dB | 0.1 | |||
Polarization Stability | Max | dB | 0.1 | 0.1 | 0.15 | |
Uniformity (50:50) | Max | dB | 0.6 | 0.8 | 1.0 | |
Thermal Stability | Max | dB | 0.2 | 0.3 | 0.4 | |
Directivity | Min | dB | 50 (1x2), 60 (2x2) | |||
Reflectance | Min | dB | 50 (1x2), 60 (2x2) | |||
Operating Temperature | °C | -30 ~ 85 | ||||
Storage Temperature | °C | -40 ~ 85 | ||||
Insertion Loss
| 50/50 | Max | dB | 3.3/3.3 | 3.4/3.4 | 3.6/3.6 |
45/55 | 3.8/2.9 | 3.9/3.0 | 4.0/3.1 | |||
40/60 | 4.3/2.5 | 4.4/2.6 | 4.6/2.7 | |||
35/65 | 4.9/2.1 | 5.0/2.2 | 5.2/2.3 | |||
30/70 | 5.6/1.8 | 5.7/1.85 | 5.9/1.9 | |||
25/75 | 6.4/1.45 | 6.5/1.55 | 6.7/1.6 | |||
20/80 | 7.4/1.15 | 7.5/1.2 | 7.7/1.3 | |||
15/85 | 8.7/0.9 | 8.8/0.95 | 9.0/1.0 | |||
10/90 | 10.5/0.6 | 10.6/0.7 | 10.8/0.8 | |||
5/95 | 13.7/0.35 | 13.8/0.4 | 14.0/0.5 | |||
1/99 | 21.0/0.15 | 21.3/0.2 | 21.6/0.25 | |||
Packaging & Delivery
Packaging Detail: | transparent plastic box (or customer specified) |
Delivery Detail: | 3-5days |
Competitive Advantage
MXT strictly enforce the ISO9001 quality management system, companies with good facilities and qualified human resources management to ensure product quality stability and excellent performance; and good after-sales service, to win the trust of customers, products exported to Europe and the United States and Southeast Asian countries.
