GJPFJV
MXT
Model Number | GJPFJV |
Type | Cat 1 |
Applicatable Mode | Single Mode & Multimode |
Jacket | PVC |
Factory | Yes |
Standards | YD/T 1258.3-2003 ICES-596 |
Installation Temperature | -5℃~+50℃ |
Crush Resistation | 200~100N/100mm |
Storage/Operation Temperature | -20℃~+60℃ |
Description
GJFPJV multi-purpose distribution cable use 6 -fibre subunits (900um tight buffer fibre, aramid yarn as strength member ).
A fibre reinforced plastic(FRP) locates in the center of core as a non-metallic strength member . The subunits are thestranded around the cable core. The cable is completed with a LSZH (Low smoke, Zero Halogen,Flame-retardant)jacket.
Characteristics
● Stranded non-metallic strength member structure ensure the cable endure larger tensile strength ;
● Compact structure with high fibre capcity and density ;
●The jacket anti-corrosion,anti-water,anti-ultraviolet radiation,flame-retardant and harmless to environment ect;
● All dielectric structure protect it from electromagnetic influence;
● Scientific design with serious processing art .
Packing & Shipping
1.Standard Packaging
Rolled by wooden drums. 1000m to 3000m/drum or other required.
2. Sheath mark
The following printing is applied at 1-meter intervals.
a. Supplier: MXT or as customer required
b. Standard Code(Product Type, Fiber Type, Fiber Count)
c. Year of manufacture: xxx
d. Length mark in meters
