MXT
Specifications
● High Return Loss & Low Insertion Loss
● High reliability and stability
● Green Production, CE, RoHS Standard
Parameter
Mode | Single mode | Multimode | |
Polish | UPC | APC | PC |
Insertion Loss | ≤0.2dB | ≤0.3dB | ≤0.2dB |
Return Loss | ≥55dB | ≥65dB | ≥35dB |
Interchangeability | ≤0.2dB | ||
Salt Spray | ≤0.1dB | ||
Repeatability | ≤0.1dB (1000 times) | ||
Vibration | ≤0.2dB (550Hz 1.5mm) | ||
Temperature | ≤0.2dB (-40+85 sustain 100 hours) | ||
Humidity | ≤0.2dB (+25+65 93 R.H.100 hours) | ||
Apex Offset | 0μm ~ 50μm | ||
Radius of Curvature | 7mm ~ 25mm | ||
Standards-Compliant | ROHS,IEC and GR-326 | ||
Fiber cable performance specifications | |||
Fiber type | Min.Bandwidth | Distance | attenuation |
62.5/125 | 850/1300nm 200/500 MHz/Km | @100Mbps 2km @1Gig 220m | 850/1300nm 3.0/1.0dB/km |
50/125 | 850/1300nm 500/500 MHz/Km | @100Mbps 2km @1Gig 500m | 850/1300nm 3.0/1.0dB/km |
50/125 10Gig Optimized | 850/1300nm 2000/500 MHz/Km | @100Gig Varies by VCSEL typical 300m 2850nm | 850/1300nm 3.0/1.0dB/km |
9/125 | 1310/1550nm Approx 100 Terahertz | Up to 100km Varies by transceiver | 1310/1550nm 0.4/0.3dB/km |
Fiber type | Single mode:1,9/125-G652D |
Multimode:4,50/125-OM2 | |
Fiber | Corning,China Fiber,other |
Connector1 | SC,FC,LC,ST,MU,DIN,MTRJ,E2000,MPO,SMA,D4 and others |
Polishing | PC,UPC,APC,MTRJ Male connector,MTRJ female connector |
Connector2 | SC,FC,LC,ST,MU,DIN,MTRJ,E2000,MPO,SMA,D4 and others |
Polishing | PC,UPC,APC,MTRJ Male connector,MTRJ female connector |
Cord type | Simplex ,Duplex |
Cable diameter | 0.9mm ,2.0mm,1.8mm 3.0mm |
Cable jacket | PVC,LSZH,OFNR,OFNP |
length(M) | 0.5m,1m,3M,5m,10m,20m,200m |
Application
● Optical fiber communications system
● Optical fiber access networks
● Optical fiber CATV
● Optical fiber test equipments
● Optical fiber data communication
MXT strictly enforce the ISO9001 quality management system, companies with good facilities and qualified human resources management to ensure product quality stability and excellent performance; and good after-sales service, to win the trust of customers, products exported to Europe and the United States and Southeast Asian countries.
